Two-component high-pressure airless sprayer, combining high efficiency with precision mixing technology, specifically designed for industrial-grade two-component coating applications. The equipment supports multiple mixing ratios from 1:1 to 1:4, meeting the precise proportioning requirements of different chemical system materials. Widely applicable for colored tile spraying, door industry adhesive spraying, interior and exterior wall latex paint coating; as well as heavy anti-corrosion and decorative projects for various industrial facilities, including: furniture, steel structures, oil tanks, lifting equipment, chemical equipment, automobiles, and trailers.
The craft features of high pressure airless spraying is higher production efficiencycompared with normal spraying gun, closely attached coating layer, it can be sprayed for100 seconds(No.4 Ford Cup)with the following varied bottom coatings.oil coatings.magnetic coatings、latex coatings for interior and exterior walls and other WB coatings.It is applicable to the colored tile spraying.latex coatings of interior and exterior walls.furniture、steel structure、chemical and industrial equipments. cars.trailers.Tubing.lifting equipment.
Features
|
Feature |
Description |
|
Super wear-resistant plunger pump body |
Maintenance cost saves 3/4 per year compared to electric pump |
|
Driven by compressed air, safety and explosion-proof |
Extremely low maintenance rate |
|
Less paint splash, less waste, paint-saving and environmentally friendly |
Professional spraying volume 30,000 liters per year |
Product Parameters
|
Model |
GP12C |
|
Pressure exchanging rate |
30:1 |
|
Maximum flow rate (L/min) |
6 |
|
Compressed air (MPa) |
0.3-0.6 |
|
Pump reciprocating rate (times/min) |
100 |
|
Cylinder diameter (mm) |
Φ125 |
|
Body weight (Kg) |
32 |
